| Output V | 36 |
| Output A | 20 |
| kW | 1.00 |
| Maximum current [A] | 6,9 |
| Length | 259 mm |
| Width | 145 mm |
| Height | 79 mm |
| Weight | 2.3 |
ZHF3620.LH
Automatic high frequency battery chargers specific for lithium batteries recharging
Complete with button for reactivation “BMS” battery
Salable only and exclusively with Zenith Lithium batteries series
- The normal output current is CONSTANT CURRENT.
- All devices are endowed with power cable (SHUKO 16A mains plug included where possible).
- All devices are supplied with output cables of 2,5MT, but WITHOUT the connector to the battery.
- The battery connectors are supplied on request.
- Mains supply: single-phase 185V/265V – Three-phase 340V/460V
- Frequency:47/62 Hz
- Efficiency: single-phase >85% – three-phase >90%
- Reccommended temperature at work: -10°C / +50°C
